Transaxle mounting bolt removal note

WARNING: This page is about a different car, the 2014 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

WARNING:

Remove the transaxle carefully, holding it steady. If the transaxle falls it could be damaged or cause injury.

Adjust the SST and lean the engine toward the transaxle.

Fig 1: Removing Transaxle Holding Steady
Courtesy of MAZDA MOTORS CORP.
Support the transaxle on a jack.
Remove the transaxle mounting bolts (lower side).
Remove the transaxle.

Fig 2: Supporting Transaxle On Jack
Courtesy of MAZDA MOTORS CORP.
