Mazda
>>
2014
>>
3 SV, Automatic Trans
>>
Repair and Diagnosis
>>
Engine Performance
>>
Fuel Delivery
>>
Fuel System
>>
Fuel Tank Removal/Installation
>>
U.S.A. and CANADA
U.S.A. and CANADA
Fig 1: Fuel Pump Relay With Torque Specifications (U.S.A. And Canada)
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
