Home >> Mazda >> 2013 >> CX-5 Sport, AWD >> Repair and Diagnosis >> Electrical >> Body Electrical >> OEM Connector End Views >> Connector End Views >> Windshield Wiper Motor Connector End View

Windshield Wiper Motor Connector End View

Fig 1: Windshield Wiper Motor Connector End View

G09077563

Courtesy of MAZDA MOTORS CORP.
