Rear Side
- Disconnect the negative battery cable.
- Remove the sail inner garnish. (See SAIL INNER GARNISH REMOVAL/INSTALLATION ).
- Remove the Rear door trim. (See REAR DOOR TRIM REMOVAL/INSTALLATION ).
- Disconnect the power window motor connector.
- Apply battery positive voltage and connect the ground to the power window motor terminals, and then inspect the power window motor operation.
- If the power window motor does not operate as indicated in the table, replace it.
Operation Terminal E F Open Ground B+ Close B+ Ground
