Radiator Mount Installation Note

WARNING: This page is about a different variant/trim than selected.
  1. Install the radiator mount so that the arrow on it is pointed toward the front of the vehicle as shown in figure.
    Fig 1: Identifying Radiator Mount Installation Position
    G06732511Courtesy of MAZDA MOTORS CORP.
