Component Test - Starter Motor Relay

Fig 1: Identifying Starter Motor Relay Terminals

Courtesy of MAZDA MOTORS CORP.

TERMINALS REFERENCE CHART

Circuit to Test	Connect Ohmmeter to Terminals	A Good Relay Will Indicate
Coil	1 and 2	100-150Ω
Coil - Contact	3 and 5	Open Circuit

TERMINALS REFERENCE CHART

Circuit to Test	Connect Ohmmeter to Terminals	A Good Relay Will Indicate
Coil - Contact	1 and 3	Open Circuit
Coil - Contact	1 and 5	Open Circuit

All vehicles
