Engine Technical Data

ENGINE TECHNICAL DATA

Item Specification
13B-MSP (Standard power) 13B-MSP (High power)
MECHANICAL
Drive belt deflection (with pressure of 98 N {10 kgf, 22 lbf}) (mm {in}) Generator New 4.0-4.5 {0.16-0.17}
When adjusting 4.5-5.0 {0.18-0.19}
Deflection limit 6.0 {0.24} or less
A/C New 3.0-3.8 {0.11-0.14}
When adjusting 3.3-4.0 {0.13-0.15}
Deflection limit 5.5 {0.21} or less
Drive belt tension (when using the SST  ) (N {kgf, lbf}) Generator New 620-767 {63.3-78.2, 140-172}
When adjusting 519-666 {53.0-67.9, 117-149}}
Deflection limit 344 {35.1, 77.3} or less
A/C New 559-706 {57.1-71.9, 126-158}
When adjusting 519-617 {53.0-62.9, 117-138}
Tension limit 265 {27.1, 59.6} or less
Compression pressure (kPa {kgf/cm2 , psi} [rpm] Standard 830 {8.5, 120} [250 rpm]
Minimum 680 {6.9, 98.6} [250 rpm]
Standard difference in chambers Within 150 {1.5, 21.8}
Standard difference in rotors Within 100 {1.0, 14.5}
Pushing distance of the rear oil seal Until it is attached to the seating face of stationary gear
Idle speed (rpm) AT 760-860
MT 750-850
Idle-up speed(1) (rpm) Electrical loads on(1) 4-speed AT [RC4A-EL] N range 780-880 -
D range 760-860 -
R range 730-830 -
6-speed AT [SJ6A-EL] N range - 780-880
D range - 760-860
R range - 740-840
MT Neutral - 750-850
A/C (standard) 4-speed AT [RC4A-EL] N range 750-850 -
D range 780-880 -
R range 760-860 -
6-speed AT [SJ6A-EL] N range - 780-880
D range - 760-860
R range - 750-850
MT Neutral - 760-860
A/C on (standard)+ electrical loads on(1) 4-speed AT [RC4A-EL] N range 780-880 -
D range 760-860 -
R range 730-830 -
6-speed AT [SJ6A-EL] N range - 780-880
D range - 760-860
R range - 750-850
MT Neutral - 790-890
A/C on (heavy load) 4-speed AT [RC4A-EL] N range 800-900 -
D range 780-880 -
R range 780-880 -
6-speed AT [SJ6A-EL] N range - 800-900
D range - 780-880
R range - 780-880
MT Neutral - 790-890
LUBRICATION SYSTEM
Oil pressure (reference value) [oil temperature: 100°C {212°F}] (kPa {kgf/cm2 , psi} [rpm]) 350 {3.57, 50.8} [3,000]
Oil capacity (approx. quantity) Oil replacement (L {US qt, Imp qt}) 3.3 {3.5, 2.9}
Oil and oil filter replacement (L {US qt, Imp qt}) 3.5 {3.7, 3.1}
Engine overhaul (L {US qt, Imp qt}) 4.7 {5.0, 4.1}
Total (dry engine) (L {US qt, Imp qt}) 5.7 {6.0, 5.0} 6.4 {6.8, 5.6}
COOLING SYSTEM
Coolant capacity (approx. quantity) (L {US qt, Imp qt}) 9.8 {10.4, 8.6}
Cooling system cap valve opening pressure (kPa {kgf/cm2 , psi}) 73.3-103.3 {0.748-1.053, 10.63-14.98}
Thermostat Initial-opening temperature (°C {°F}) 80-84 {176-183}
Full-opening temperature (°C {°F}) 95 {203}
Full-open amount (mm {in}) 8.5 {0.33} or more
Cooling fan motor current [12 V] (A) Cooling fan No.1: 8.9-11.9
Cooling fan No.2: 4.0-7.0
FUEL SYSTEM
Fuel line hold pressure (kPa {kgf/cm2 , psi}) 375-450 {3.83-4.58, 54.4-65.2}
Fuel injector Leakage Position: FP1, RP1 1 drop/110 min. or more
Position: FS, RS 1 drop/30 min. or more 1 drop/70 min. or more
Position: FP2, RP2 - 1 drop/70 min. or more
Resistance [20°C {68°F}] (ohm) 13.8
CHARGING SYSTEM
Battery Electrolyte specific gravity 1.22-1.29 [20°C {68°F}]
Back-up current(2) (Vehicles with immobilizer system) (mA) 25-45 (The average value, indicates around 30.)
Back-up current(2) (Vehicles without immobilizer system) (mA) 30 or less
Test load chart (A) Battery type (5-hour rate) 75D23L (52) 195
Slow charge (A) Battery type (5-hour rate) 75D23L (52) 5.0-6.0
Quick charge (A/30 min) Battery type (5-hour rate) 75D23L (52) 35
Generator Rotor resistance (Between slip rings) (ohm) 1.6-2.0
Brush length Standard (mm {in}) 18.5 {0.73}.
Minimum (mm {in}) 5.0 {0.2}
Brush spring force Standard (N {kgf, lbf}) 4.8-6.0 {0.49-0.61, 1.08-1.34}
Minimum (N {kgf, lbf}) 2.16 {0.22, 0.49}
Standard voltage (V) Ignition switch ON Terminal B B+
P Approx. 1.0 or less
D Approx. 0
Idle [20 °C {68 °F}] Terminal B 13.0-15.0
P Approx. 3.0-8.0
D (6)
Generated current (reference value) (A) Terminal B current [Engine speed 1,000 rpm] 0(3)-70
Terminal B current [Engine speed 2,000 rpm] 0(3)-97
IGNITION SYSTEM
Firing order When idling: T/F-L/F-T/R-L/R
Except for idling: L/F-T/F-L/R-T/R (Independent ignition control)
Spark plug Type Leading side N3H5 18 110 (RE7C-L)(4)
N3Y8 18 110 (RE7C-L)(4)
N3Y9 18 110 (RE6C-L)(5)
Trailing side N3H1 18 110C (RE9B-T)(4)
N3Y1 18 110 (RE9B-T)(4)
Plug gap Standard (mm {in}) 1.15-1.25 {0.046-0.049}
Maximum (mm {in}) Leading side: 1.5 {0.059}
Trailing side: 1.4 {0.055}
Resistance [25°C {77°F}] (kilohm) 3.0-7.5
Tightening torque (N.m {kgf.cm, in.lbf}) 12.8-17.7 {131-180, 114-156}
High-tension lead Resistance [20°C {68°F}] (kilohm) 1.0-4.0
STARTING SYSTEM
Starter Commutator diameter Standard (mm {in}) 29.4 {1.16}
Minimum (mm {in}) 28.8 {1.13}
Brush length Standard (mm {in}) AT: 17.5 {0.69}, MT: 12.3 {0.48}
Minimum (mm {in}) AT: 12.0 {0.47}, MT:7.0 {0.28}
Brush spring force Standard (N {kgf, lbf}) AT: 23.3-31.7 {2.38-3.23, 5.24-7.12},
MT: 18.3-24.9 {1.87-2.53, 4.12-5.59}
Minimum (N {kgf, lbf}) AT: 10.0 {1.02, 2.25}
MT: 5.9 {0.6, 1.3}
Pinion gap (mm {in}) AT: 0 {0}, MT: 0.5-2.0 {0.02-0.07}
No load test Voltage (V) 11
Current (A) 120 or less
(1) The headlight, rear window defroster, blower fan (2-step or more) are on.
(2) Back-up current is the constant flow of current (for audio unit, clock, PCM, etc.) that is supplied after leaving the battery undisturbed for approx. 30 min when the ignition switch is off (key has been removed) and all doors are closed.
(3) The lower limit of current must be more than 0 A.
(4) Standard equipment
(5) Hot type plug: Available only for customers who often drive their car at very low speed which causes the plugs to foul easily.
(6) Turn the following electrical loads on and verify that the voltage reading increases.
  • Headlights
  • Blower motor
  • Rear window defroster
ENGINE OIL SPECIFICATION

Item U.S.A. and CANADA Except U.S.A. and CANADA
Engine oil grade
G04563033Courtesy of MAZDA MOTORS CORP.
G04563034Courtesy of MAZDA MOTORS CORP.
Engine oil viscosity 5W-20
