Child-Restraint Seat Anchor Removal/Installation

  1. Remove the trunk end trim bezel.
  2. Remove in the order indicated in the table.
    Fig 1: View Of Trunk End Trim Bezel With Torque Specifications
    G04860856Courtesy of MAZDA MOTORS CORP.
  3. Install in the reverse order of removal.
