DTC B2296: Notes
DTC B2296 DETECTION CONDITION AND POSSIBLE CAUSES
| DTC B2296 |
Crash zone sensor system (communication error, sensor internal circuit abnormal) |
| DETECTION CONDITION |
WARNING:
- Detection conditions are for understanding DTC outline before performing inspection. Performing inspection with only detection conditions may cause injury due to operating error or damage the system. When performing inspection, always follow inspection procedure.
- Malfunction in wiring harness between crash zone sensor and SAS control module
- Malfunction in crash zone sensor circuit
|
| POSSIBLE CAUSE |
- Open or short circuit in wiring harness between crash zone sensor and SAS control module
- SAS control module malfunction
- Crash zone sensor malfunction
|
|
|
