DTC C1947, C1948, C1981: Notes
DTC C1947, C1948, C1981 DETECTION CONDITION AND POSSIBLE CAUSES
| DTC |
C1947 |
Seat track position sensor circuit short to ground |
| C1948 |
Seat track position sensor circuit resistance out of range |
| C1981 |
Seat track position sensor circuit open or short to power supply |
| DETECTION CONDITION |
WARNING:
- Detection conditions are for understanding DTC outline before performing inspection. Performing inspection with only detection conditions may cause injury due to operating error or damage the system. When performing inspection, always follow inspection procedure.
- Malfunction in seat track position sensor circuit.
|
| POSSIBLE CAUSE |
- Malfunction of connector between seat track position sensor and SAS control module.
- Open or short circuit in wiring harness between seat track position sensor and SAS control module.
- Seat track position sensor malfunction
- SAS control module malfunction
|
|
|
