DTC P0773: Notes
DTC P0773 [FN4A-EL] DETECTION CONDITION CHART
| DTC P0773 |
Shift solenoid E malfunction (electrical) |
| DETECTION CONDITION |
- If PCM detects either of the following conditions while driving in 4GR at D range with TCC operating, PCM determines that shift solenoid E circuit has a malfunction.
- Shift solenoid E voltage stuck at B+
after engine start
- Shift solenoid E voltage stuck at 0 V
after engine start
Diagnostic support note:
- This is a continuous monitor (CCM).
- The MIL illuminates if the PCM detects the above malfunction conditions during the first drive cycle.
- A PENDING CODE is not available.
- FREEZE FRAME DATA is available.
- The AT warning light illuminates.
- The DTC is stored in the PCM memory.
|
| POSSIBLE CAUSE |
- Shift solenoid E malfunction
- Short to ground in wiring harness between ATX terminal F and PCM terminal 1F
- Short to power supply in wiring harness between ATX terminal F and PCM terminal 1F
- Open circuit in wiring harness between shift solenoid E terminal A and ATX terminal F
- Open circuit in wiring harness between ATX terminal F and PCM terminal 1F
- Damaged connector between shift solenoid E and PCM
- PCM malfunction
|
|
|
