DTC P0753: Notes
DTC P0753 [FN4A-EL] DETECTION CONDITION CHART
| DTC P0753 |
Shift solenoid A malfunction (electrical) |
| DETECTION CONDITION |
- If PCM detects either of the following conditions, PCM determines that shift solenoid A circuit has a malfunction.
- Shift solenoid A voltage stuck at B+
after engine start
- Shift solenoid A voltage stuck at 0 V
after engine start
Diagnostic support note:
- This is a continuous monitor (CCM).
- The MIL illuminates if the PCM detects the above malfunction conditions during the first drive cycle.
- A PENDING CODE is not available.
- FREEZE FRAME DATA is available.
- The AT warning light illuminates.
- The DTC is stored in the PCM memory.
|
| POSSIBLE CAUSE |
- Shift solenoid A malfunction
- Short to ground in wiring harness between ATX terminal A and PCM terminal 1B
- Short to power supply in wiring harness between ATX terminal A and PCM terminal 1B
- Open circuit in wiring harness between shift solenoid A terminal B and ATX terminal A
- Open circuit in wiring harness between ATX terminal A and PCM terminal 1B
- Open circuit in wiring harness between shift solenoid A terminal A and body ground
- Damaged connector between shift solenoid A and PCM
- PCM malfunction
|
|
|
