Removal and Installation

  1. Remove the air cleaner outlet tube. See AIR CLEANER OUTLET PIPE -- 2.3L .
    Fig 1: Removing Air Cleaner Outlet Tube
    G03724999Courtesy of MAZDA MOTORS CORP.
  2. Disconnect the mass air flow (MAF/IAT) sensor electrical connector.
    Fig 2: Disconnecting Mass Air Flow Sensor Electrical Connector
    G03725000Courtesy of MAZDA MOTORS CORP.
  3. Remove the four nuts and the MAF/IAT sensor.
  4. To install, reverse the removal procedure.
