Valve - Guide Inner Diameter

    Fig 1: Measuring Valve Guide Inner Diameter
    G00984648Courtesy of MAZDA MOTORS CORP.
  1. Measure the inner diameter of the valve guides in two directions where indicated. Refer to SPECIFICATIONS .
  2. If the valve guide is not within specifications, ream the valve guide and install a valve with an oversize stem or remove the valve guide and install a new valve guide.
