Home >> Mazda >> 2004 >> MPV ES >> Repair and Diagnosis >> Engine Performance >> System >> On-Board Diagnostic [Engine Control System AJ] >> DTC P0107: EGR Boost Sensor Circuit Low Input >> Diagnostic Procedure

Diagnostic Procedure

Fig 1: DTC P0107 Diagnostic Procedure Chart
G00992263Courtesy of MAZDA MOTORS CORP.
