External Sealing

The transmission has the following parts to prevent external fluid leakage:

• Gaskets
• Lip-type seals
• O-ring seals
• Seal rings
• Seal grommets
• Thread sealant
  Fig 1: Locating Area For Fluid Leakage

  Courtesy of MAZDA MOTORS CORP.
