Socket Removal Note

Insert a tape-wrapped flathead screwdriver into the socket hole, then push on the ring protrusion to lift the socket toward you.

Fig 1: Inserting Tape-Wrapped Flathead Screwdriver Into Socket Hole
Courtesy of MAZDA MOTORS CORP.
As shown in the figure, lift out the socket until the ring protrusion locks into the lower socket hole.

Fig 2: Lifting Out Socket Until Ring Protrusion Locks Into Lower Socket Hole
Courtesy of MAZDA MOTORS CORP.
Remove the boot panel.
Front behind the boot panel, slide a tape-wrapped flathead screwdriver in between the socket and the ring protrusion.

Fig 3: Removing Boot Panel
Courtesy of MAZDA MOTORS CORP.
While twisting the ring protrusion with the screwdriver, push out and remove the socket.
