Engine Controls - Tests W/Codes
>>
Trouble Code Identification
>>
Code 3: (SGT Signal - Crank Angle)
Code 3: (SGT Signal - Crank Angle)
Fig 1: Trouble Code No. 3 Diag. Chart (SGT Signal - Crank Angle)
Courtesy of MAZDA MOTORS CORP.
Courtesy of MAZDA MOTORS CORP.
