Evaporative Emissions System - MAZDA - Piston Engine: Maintenance

Check complete system, hose connections, and clamps for proper operation every 12, 000 miles.

Fig 1: Evaporation Emission Control System (Typical)

Courtesy of MAZDA MOTORS CORP.
