Selector Lever Cable: Removal

All vehicles

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to Jacking and Lifting .
2. Remove the selector lever bezel. Refer to Selector Lever Bezel .

3. Courtesy of FORD MOTOR COMPANY

4. Courtesy of FORD MOTOR COMPANY

5. Courtesy of FORD MOTOR COMPANY

6. Courtesy of FORD MOTOR COMPANY

7. Courtesy of FORD MOTOR COMPANY

8. NOTE: Note the routing of the selector lever cable under the heater housing for assembly.

   Courtesy of FORD MOTOR COMPANY

   6F50/6F55

9. Remove the ACL and outlet pipe. Refer to Intake Air Distribution and Filtering .

10. Courtesy of FORD MOTOR COMPANY

11. Courtesy of FORD MOTOR COMPANY

6F35

12. Remove the ACL assembly. Refer to Intake Air Distribution and Filtering .

13. Courtesy of FORD MOTOR COMPANY

14. Courtesy of FORD MOTOR COMPANY

All vehicles

15. Courtesy of FORD MOTOR COMPANY

16. Courtesy of FORD MOTOR COMPANY
