WARNING: This page is about a different car, the 2016 Lincoln MKX. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Module Communications Network Wiring Diagram (1 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 2: Module Communications Network Wiring Diagram (2 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 3: Module Communications Network Wiring Diagram (3 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 4: Module Communications Network Wiring Diagram (4 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 5: Module Communications Network Wiring Diagram (5 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 6: Module Communications Network Wiring Diagram (6 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 7: Module Communications Network Wiring Diagram (7 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 8: Module Communications Network Wiring Diagram (8 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 9: Module Communications Network Wiring Diagram (9 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 10: Module Communications Network Wiring Diagram (10 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 11: Module Communications Network Wiring Diagram (11 of 12)
Courtesy of FORD MOTOR COMPANY
Fig 12: Module Communications Network Wiring Diagram (12 of 12)
