Catalytic Converter - RH: Installation

All vehicles

NOTE: Make sure to tighten the 4 new nuts in the following sequence.
1. Install a new RH catalytic converter gasket, position the RH catalytic converter and tighten the 4 new nuts in the sequence shown in illustration.
   • Tighten to 40 Nm (30 lb-ft).
     Fig 1: Identifying RH Catalytic Converter Nuts Tightening Sequence

     Courtesy of FORD MOTOR CO.

   All-Wheel Drive (AWD) vehicles

2. Install the transaxle support insulator - anti roll. For additional information, refer to AUTOMATIC TRANSMISSION - 6F50/6F55 .

   All vehicles

3. Install the exhaust Y-pipe. For additional information, refer to EXHAUST Y-PIPE .
4. Install the CMS. For additional information, refer to ELECTRONIC ENGINE CONTROLS .
5. Start the engine and check for exhaust leaks.
