Power Steering Fluid Cooler: Notes

Material Specification

Item	Specification
MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US); XT-2-LM12 (Canada)	MERCON®

Fig 1: Exploded View Of Power Steering Fluid Cooler With Torque Specifications

GF0014236

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	N606676	Cooling module mounting bracket bolt (2 required)
2	8125	Cooling module mounting bracket (2 required)
3	N806799	Air side shield upper pushpins (4 required)
4	19E572	Cooling module side shield (2 required)
5	8005	Radiator
6	3D746	Power steering fluid cooler
