In-line C313M, C313F

WARNING: This page is about a different car, the 2003 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying In-Line C313M, C313F
G03590460Courtesy of FORD MOTOR CO.
