Removal and Installation

  1. Disconnect the battery ground cable.
    CAUTION: Prior to removal of the module, it is necessary to upload module configuration information to the appropriate diagnostic equipment. This information needs to be downloaded into the new module once installed. For additional information, see MODULE CONFIGURATION .
    CAUTION: Electronic modules are sensitive to electrical charges. If exposed to these charges, damages may result.
  2. Remove the driver door trim panel. For additional information, see TRIM PANEL -- FRONT DOOR .
  3. Remove the driver door module.
    1. Disconnect the electrical connectors.
    2. Remove the three bolts.
    3. Remove the DDM.
    Fig 1: Removing Driver Door Module
    G01274918Courtesy of FORD MOTOR CO.
  4. To install, reverse the removal procedure.
