Upper Arm: Notes

WARNING: This page is about a different car, the 2010 Lincoln Town Car. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Upper Arm With Torque Specifications
GF0046738Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W712820 Upper arm-to-frame bolt
2 5501 Upper arm
3 W707060 Upper arm-to-frame flagnut
4 W506545 Upper arm-to-axle bolt
5 W704662 Upper arm-to-axle nut
