Audio Control Module (ACM) C290e

WARNING: This page is about a different car, the 2005 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Audio Control Module (ACM) C290e
G03998804Courtesy of FORD MOTOR CO.
