MOTORCRAFT Starter Specifications
MOTORCRAFT STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Brush Length | ||
| Original | .45" (11.4 mm) | |
| Service Limit | .25" (6.4 mm) | |
| Brush Spring Tension | 80 oz. (2.3 kg) | |
| Load Test Current Draw | ||
| 4" | 150-250 Amps | |
| 4 1/2" | 150-210 Amps | |
| No-Load Test Current Draw | ||
| 4" | 80 Amps | |
| 4 1/2" | 85 Amps | |
| Through Bolt Torque | 45-85 INCH Lbs. (5.0-9.6 N.m) | |
