DTC P0195-11: Engine Oil Temperature Sensor Circuit Short to Ground [12/2021 - ]: Procedure

Pre-procedure1

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

1. Disconnect the engine oil temperature sensor connector.

   Procedure1

2. According to the display on the GTS, read the Data List.

   Powertrain > Engine > Data List

   Tester Display
   Engine Oil Temperature Sensor

   Result

   Result	Proceed to
   The value of Engine Oil Temperature Sensor is -40°C	A
   None of the above conditions are met	B

   HINT:

   -40°C (-40°F)

   Post-procedure1

3. None

Result:

A

REPLACE ENGINE OIL TEMPERATURE SENSOR (TEMPERATURE SENSOR). Refer to  REMOVAL [12/2021 - ]

Result:

B

See step  2

Pre-procedure1

1. Disconnect the engine oil temperature sensor connector.
2. Disconnect the ECM connector.

   Procedure1

3. Measure the resistance according to the value(s) in the table below.

   Standard Resistance

   Tester Connection	Condition	Specified Condition
   C7-2 (TOUT) or C37-74 (THEO) - Body ground and other terminals	Always	10 kΩ or higher

   Result

   Proceed to
   OK
   NG

   Post-procedure1

4. None

Result:

OK

REPLACE ECM. Refer to  REMOVAL [12/2021 - ]

Result:

NG

REPAIR OR REPLACE HARNESS OR CONNECTOR
