Components [03/2018 - ]

Fig 1: Radio Receiver Replacement Components [03/2018 - ] (1 Of 3)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*A	w/o Rear No. 2 Seat	-	-
*1	DECK BOARD ASSEMBLY	*2	REAR DECK FLOOR BOX

Fig 2: Main Body ECU Replacement Components [03/2018 - ] (2 Of 3)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*A	w/ Rear No. 2 Seat	-	-
*1	BATTERY SERVICE HOLE COVER	*2	REAR NO. 4 FLOOR BOARD

Fig 3: Integration Relay Replacement Components With Torque Specifications [03/2018 - ] (3 Of 3)

Callout	Description	Callout	Description
*1	COOL AIR INTAKE DUCT SEAL	*2	FRONT FENDER REINFORCEMENT SUB-ASSEMBLY TOP LH
*3	NO. 1 RELAY BLOCK COVER	*4	NO. 2 ENGINE ROOM RELAY BLOCK
*5	NO. 6 INVERTER BRACKET	*6	SEMICONDUCTOR POWER INTEGRATION ECU
*7	WIRING HARNESS CLAMP BRACKET	*8	CENTER HOOD CUSHION
	Nm (kgfcm, ft.*lbf): Specified torque	-	-
