Pre-Collision System Warning Buzzer
>>
Components [01/2023 - ]
Components [01/2023 - ]
Fig 1: Pre-Collision System Warning Buzzer Replacement Components [01/2023 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
HOOD LOCK CONTROL LEVER SUB-ASSEMBLY
*2
LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY
*3
NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
*4
SKID CONTROL BUZZER
