Front Turn Signal Light Bulb
>>
Components [06/2018 - ]
Components [06/2018 - ]
Fig 1: Front Turn Signal Light Bulb Replacement Components [06/2018 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
FRONT TURN SIGNAL LIGHT BULB
*2
REAR FENDER SPLASH SHIELD SUB-ASSEMBLY
*3
FRONT FENDER LINER RETAINER
*4
PIN HOLD CLIP
