Sliding Roof Switch Assembly
>>
Components [10/2015 - 11/2017]
Components [10/2015 - 11/2017]
Fig 1: Sliding Roof Switch Assembly Replacement Components [10/2015 - 11/2017]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1
MAP LIGHT ASSEMBLY
*2
NO. 1 ROOF CONSOLE BOX COVER
*3
TELEPHONE MICROPHONE ASSEMBLY
*4
SLIDING ROOF SWITCH (MAP LIGHT ASSEMBLY)
