Components [10/2023 - ]

WARNING: This page is about a different car, the 2024 Lexus LS 500, 2023 Lexus LS 500, 2022 Lexus LS 500, and 2021 Lexus LS 500. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Millimeter Wave Radar Sensor Replacement Components With Torque Specifications [10/2023 - ]
GTY1232939Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 LOWER RADIATOR AIR DEFLECTOR *2 MILLIMETER WAVE RADAR SENSOR ASSEMBLY
*3 RADIATOR COVER PLATE *4 UPPER RADIATOR SUPPORT SEAL
N.m (kgf/cm, ft.lbf): Specified torque - -
