Wiper System / Washer System - Service Information
>>
Washer Motor
>>
Components [11/2021 - ]
Components [11/2021 - ]
Fig 1: Washer Motor Replacement Components [11/2021 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*A
except 2UR-GSE
*B
for 2UR-GSE
*1
FRONT FENDER LINER LH
*2
FRONT WHEEL OPENING EXTENSION PAD LH
*3
WINDSHIELD WASHER MOTOR AND PUMP ASSEMBLY
-
-
