Components [10/2015 - ]

Fig 1: Mass Air Flow Meter Replacement Components With Torque Specifications (1 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Callout	Description	Callout	Description
*1	OUTER COWL TOP PANEL SUB-ASSEMBLY	-	-
	Nm (kgfcm, ft.*lbf): Specified torque	-	-

Fig 2: Mass Air Flow Meter Replacement Components With Torque Specifications (2 Of 2)

Callout	Description	Callout	Description
*1	AIR CLEANER ASSEMBLY WITH AIR CLEANER HOSE	*2	COOL AIR INTAKE DUCT SEAL
*3	INLET AIR CLEANER ASSEMBLY	*4	MASS AIR FLOW METER SUB-ASSEMBLY
*5	INVERTER DRAIN HOSE	-	-
	Nm (kgfcm, ft.*lbf): Specified torque	-	-
