Wiper System / Washer System - Service Information
>>
Headlight Cleaner Nozzle
>>
Components [09/2014 - 10/2018]
Components [09/2014 - 10/2018]
Fig 1: Headlight Cleaner Nozzle Replacement Components [09/2014 - 10/2018]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout
Description
Callout
Description
*1
HEADLIGHT CLEANER WASHER NOZZLE COVER LH
*2
HEADLIGHT CLEANER WASHER NOZZLE COVER RH
*3
HEADLIGHT WASHER ACTUATOR SUB-ASSEMBLY LH
*4
HEADLIGHT WASHER ACTUATOR SUB-ASSEMBLY RH
