Removal [09/2014 - ]: Procedure

  1. REMOVE FRONT WHEEL LH

    Refer to PROCEDURE - Step 1 [09/2014 - 10/2022] , or refer to PROCEDURE - Step 1 [10/2022 - ]

  2. REMOVE FRONT WHEEL OPENING EXTENSION PAD LH

    See step  2

  3. REMOVE FRONT FENDER LINER LH

    See step  3

  4. REMOVE HEADLIGHT CLEANER CONTROL RELAY
    1. Disconnect the connector.
      GTY507322Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Disengage the claw and remove the headlight cleaner control relay as shown in the illustration.
