DTC U0327: Software Incompatibility with Vehicle Security Control Module [09/2015 - ]: Wiring Diagram

Fig 1: Certification ECU (Smart Key ECU Assembly) Circuit Diagram
GTY646699Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
