Washer Level Warning Switch
>>
Components [04/2013 - 08/2015]
Components [04/2013 - 08/2015]
Fig 1: Washer Level Warning Switch Replacement Components [04/2013 - 08/2015]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*A
for 2WD
*B
for AWD
*1
COOL AIR INTAKE DUCT
*2
ENGINE UNDER COVER
*3
LEVEL WARNING SWITCH ASSEMBLY
-
-
