DTC B2424: Headlight Beam Level Control Motor LH Lost Communication; DTC B2425: Headlight Beam Level Control Motor RH Lost Communication [10/2016 - 09/2020]: Wiring Diagram

GTY675481Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
