Components [09/2020 - ]

Fig 1: Absorber Control Actuator (For Rear Side) Replacement Components [09/2020 - ] (1 Of 3)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*1	DECK SIDE TRIM BOX LH	*2	DECK SIDE TRIM BOX RH
*3	FRONT LUGGAGE COMPARTMENT TRIM COVER	*4	LUGGAGE COMPARTMENT DOOR STRIKER COVER
*5	LUGGAGE COMPARTMENT FLOOR MAT	*6	REAR LUGGAGE COMPARTMENT TRIM COVER
*7	SPARE WHEEL COVER TRAY LH	*8	SPARE WHEEL COVER TRAY RH
*9	ROPE HOOK ASSEMBLY	-	-

Fig 2: Absorber Control Actuator (For Rear Side) Replacement Components [09/2020 - ] (2 Of 3)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*A	for LH Side	*B	for RH Side
*1	FRONT UPPER LUGGAGE COMPARTMENT TRIM COVER	*2	LUGGAGE COMPARTMENT TRIM COVER LH
*3	LUGGAGE COMPARTMENT TRIM COVER RH	*4	NO. 1 LUGGAGE COMPARTMENT LIGHT ASSEMBLY
*5	ROPE HOOK ASSEMBLY	-	-

Fig 3: Absorber Control Actuator (For Rear Side) Replacement Components [09/2020 - ] (3 Of 3)

ABSORBER CONTROL ACTUATOR
