DTC B27A7: Open in Inside Luggage Compartment Electrical Key Oscillator Circuit: Wiring Diagram

WARNING: This page is about a different car, the 2011 Lexus RX 350. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Luggage Compartment Electrical Key Oscillator Circuit Wiring Diagram
GTY352800Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
