Entry Lock And Unlock Switch: Components

Fig 1: Identifying Entry Lock And Unlock Switch Components (1 Of 2)
G05754549Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Entry Lock And Unlock Switch Replacement Components (2 Of 2) with Torque Specifications
G05754571Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
