Rear Power Window RH Auto Up / Down Function does not Operate with Rear Power Window Switch RH: Wiring Diagram

Fig 1: Front Power Window Regulator Motor Assembly (For Rear LH Side) Wiring Diagram
G05755769Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
