Name Plate: Removal

HINT:

When removing the emblem and name plate, heat the vehicle body, emblem and name plate using a heat light.

Heating temperature

1. REMOVE SYMBOL EMBLEM
   1. Put protective tape around the emblem.
   2. Insert a piano wire between the vehicle body and emblem.
   3. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends.
   4. Pull the piano wire and scrape off the double-sided tape that holds the moulding to the vehicle body.
      NOTE: Be careful not to damage the vehicle body.
   5. Remove the emblem.
   Fig 1: Removing Symbol Emblem
   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. REMOVE NO. 1 LUGGAGE COMPARTMENT DOOR NAME PLATE
   1. Put protective tape around the name plate.
   2. Insert a piano wire between the vehicle body and name plate.
   3. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends.
   4. Pull the piano wire and scrape off the double-sided tape that holds the moulding to the vehicle body.
      NOTE: Be careful not to damage the vehicle body.
   5. Remove the name plate.
   Fig 2: Removing No. 1 Luggage Compartment Door Name Plate
   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
3. REMOVE NO. 3 LUGGAGE COMPARTMENT DOOR PLATE
   Fig 3: Inserting Piano Wire Between Vehicle Body And Emblem

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
   1. Put protective tape around the name plate.
   2. Insert a piano wire between the vehicle body and name plate.
   3. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends.
   4. Pull the piano wire and scrape off the double-sided tape that holds the moulding to the vehicle body.
      NOTE: Be careful not to damage the vehicle body.
   5. Remove the name plate.
