Television Display: Installation

INSTALL TELEVISION DISPLAY
1. Install the television display with the 4 nuts.
2. Connect the connector.
Fig 1: Installing Television Display
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL TELEVISION BASE
1. Engage the 4 clips and install the television base.
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION

Fig 2: Locating Clips On Television Base
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See PRECAUTION )
