Audio / Visual: Microphone: Removal

  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  2. REMOVE MAP LIGHT ASSEMBLY (See  REMOVAL  )
  3. REMOVE MICROPHONE
    1. Disconnect the connector.
    2. Remove the screw and microphone bracket.
    3. Remove the microphone.
    Fig 1: Removing Microphone Screw
    G04092841Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
