Navigation Antenna: Components

WARNING: This page is about a different car, the 2007 Lexus GX 470. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Navigation Antenna Replacement Components (1 Of 2)
G05266568Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Navigation Antenna Replacement Components (2 Of 2)
G05266569Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
