Circuit Description
The each knock sensors are fitted on the right bank and left bank of the cylinder block to detect the engine knocking.
Each sensor contains a piezoelectric element which generates a voltage when it becomes deformed, which occurs when the cylinder block vibrates due to the knocking. If the engine knocking occurs, the ignition timing is retarded to suppress it.
